图文名称：(BF25)变速操纵阀 12C0061
所属机型：CLG835
图文编号：175
物料编号：144
|
 |
|
| 详细资料 |
|
序号
Sr.No |
零件号
Part No |
旧零件号
Ref. Part No. |
名称
Nomenclature |
规格
Specifications |
数量
Qua-ntity |
|
1 |
00B0053 |
BF25-10 |
螺栓 Bolt |
|
1 |
|
2 |
12B0041 |
GB3452.1-82 |
O形圈“O”Ring |
19×2.65 |
2 |
|
3 |
75A0015 |
BF25-7 |
弹簧 Spring |
|
2 |
|
4 |
20B0005 |
GB308-84 |
钢球 Ball |
12.7G40 |
2 |
|
6 |
12B0036 |
GB3452.1-82 |
O形圈 “O”Ring |
5.3×1.8 |
1 |
|
7 |
02B0001 |
BF25-2 |
螺栓 Bolt |
|
2 |
|
8 |
12B0143 |
GB1235-76 |
O形圈 “O”Ring |
30×3.1 |
2 |
|
9 |
70A0005 |
BF25-1 |
阀体 Valve Body |
|
1 |
|
10 |
65A0012 |
BF25-8 |
分配阀杆 Range Valve Rod |
|
1 |
|
11 |
55A0075 |
BF25-11 |
挡套 Collar |
|
1 |
|
12 |
13B0006 |
HG4-692-67 |
油封 Seal |
PD18×30×10 |
1 |
|
13 |
07B0016 |
GB893.1-86 |
挡圈 Snap Ring |
30 |
1 |
|
14 |
75A0016 |
BF25-6 |
弹簧 Spring |
|
1 |
|
15 |
65A0011 |
BF25-5 |
刹车阀杆 Clutch Cutoff Valve |
|
1 |
|
16 |
61A0042 |
BF25-21 |
圆柱塞 Cylinder Plug |
|
1 |
|
17 |
12B0044 |
GB3452.1-82 |
O形圈 “O”Ring |
10×1.8 |
1 |
|
18 |
00A0037 |
BF25-22 |
接头 Connector |
|
1 |
|
19 |
03B0061 |
BF25-20 |
螺母 Nut |
|
1 |
|
20 |
15C0002 |
BF25.1 |
左阀座 Left Valve Seat |
|
1 |
|
21 |
12B0042 |
GB1235-76 |
密封垫 Gasket |
45×3.1 |
2 |
|
22 |
65A0013 |
BF25-16 |
气阀杆 Air Valve Rod |
|
1 |
|
23 |
12B0008 |
GB1235-76 |
O形圈 “O”Ring |
40×3.1 |
1 |
|
24 |
78A0005 |
BF25-15 |
气阀体 Air Valve Body |
|
1 |
|
25 |
75A0017 |
BF25-19 |
弹簧 Spring |
|
1 |
|
26 |
56A0039 |
BF25-18 |
垫 Gasket |
|
1 |
|
27 |
65A0003 |
BF25-4 |
减压阀杆 Regulator Valve Rod |
|
1 |
|
28 |
53A0038 |
BF25-30 |
弹簧座 Spring Retainer |
|
1 |
|
29 |
75A0019 |
BF25-29 |
弹簧 Spring |
|
1 |
|
30 |
56A0041 |
BF25-27 |
调压圈 Ring |
|
1组 |
|
31 |
75A0018 |
BF25-28 |
弹簧 Spring |
|
1 |
|
32 |
61A0043 |
BF25-26 |
滑块 Sliding Block |
|
1 |
|
33 |
12B0040 |
GB1235-76 |
O形圈 “O”Ring |
40×3.1 |
1 |
|
34 |
03B0024 |
BF25-24 |
螺栓 Bolt |
|
1 |
|
35 |
20B0006 |
GB308-84 |
钢球 Ball |
47625G40 |
1 |
|
36 |
56A0040 |
BF25-23 |
圆板 Plate |
|
1 |
|
37 |
00A0034 |
BF25-12A |
接头 Connector |
|
2 |
|
38 |
63A0004 |
BF25-17 |
右阀座 Right Valve Seat |
|
1 |
|
39 |
12B0043 |
GB1235-76 |
O形圈 “O”Ring |
24×2.4 |
1 |
|
40 |
00A0295 |
ZL50CIII.12-1 |
接头 Connector |
|
1 |
|
41 |
12B0231 |
GB3452.1-82 |
O形圈 “O”Ring |
18×2.65 |
1 | |
|
|
|
|
| |
|
|
|
|
